RTL AWD Specifications
Notable features
Completely redesigned for 2026
One base version (RTL), two off-road TrailSport versions
3.5-liter V-6
10-speed automatic transmission
Torque-vectoring AWD standard
RTL AWD Specifications
Notable features
Completely redesigned for 2026
One base version (RTL), two off-road TrailSport versions
3.5-liter V-6
10-speed automatic transmission
Torque-vectoring AWD standard
Highlights
19 City / 25 Hwy MPG
5 Seat capacity
Regular Unleaded V-6 Engine
All Wheel Drive Drivetrain
Engine
3.5 L/212 Displacement
Regular Unleaded V-6 Engine Type
285 @ 6100 SAE Net Horsepower @ RPM
262 @ 5000 SAE Net Torque @ RPM
Suspension
Strut Suspension Type - Front
Multi-Link Suspension Type - Rear
Strut Suspension Type - Front (Cont.)
Multi-Link Suspension Type - Rear (Cont.)
Weight & Capacity
N/A Maximum Payload Capacity
N/A Curb Weight
N/A Aux Fuel Tank Capacity, Approx
500 lbs Wt Distributing Hitch - Max Tongue Wt.
4,478 lbs Base Curb Weight
N/A Curb Weight - Front
0 lbs Total Option Weight
19 gal Fuel Tank Capacity, Approx
5,000 lbs Dead Weight Hitch - Max Trailer Wt.
5,000 lbs Maximum Trailering Capacity
N/A Curb Weight - Rear
5,000 lbs Wt Distributing Hitch - Max Trailer Wt.
500 lbs Dead Weight Hitch - Max Tongue Wt.
Safety
Standard Stability Control
Standard Rear Cross Traffic Alert
Standard Blind Spot Monitor
Standard Automatic Emergency Braking
Standard Lane Departure Warning
Standard Backup Camera
Electrical
N/A Maximum Alternator Capacity (amps)
N/A Cold Cranking Amps @ 0° F (Primary)
Brakes
4-Wheel Disc Brake Type
14 in Front Brake Rotor Diam x Thickness
N/A Brake ABS System (Second Line)
Yes Disc - Rear (Yes or )
N/A Drum - Rear (Yes or )
13 in Rear Brake Rotor Diam x Thickness
4-Wheel Brake ABS System
Yes Disc - Front (Yes or )
The good & the bad
The good
Smooth 3.5-liter V-6 engine
Off-road capability (TrailSport)
On-road drivability (TrailSport)
Roomy interior
12.3-inch touchscreen display
The bad
Poor fuel economy
Lazy on-road throttle response
Unibody construction for off-roading
Can be pricier than three-row Honda Pilot
